WKD-150 level control transmitter
Brand: Hengyuan
Model: WKD-150, WKD-300, WKD-500
Type: Intelligent pressure transmitter
Measurement medium: oil and water
Measurement range: 0~2 m (kPa)
Accuracy level: ± 0.5% annual drift <± 0.2FS
Output signal: 4~20mA (mA)
Explosion-proof grade: 5
Protection grade: 5
Power supply voltage: AC86 265V, DC110 340V (V)
Interface size: G3 / 4 (mm)
technical parameter
■The measurement range ranged from 0 to 2 m
■ power supply voltage: AC / DC general-purpose AC85~265V, DC110~340 or DC24V, as determined when ordering
■ parameter display: four-digit LED display window setting and measurement parameter 3LED indicator light
■ output mode: 3LED indicator displays the alarm action state, 1 analog amount and 3 switch amount
■ output current: 4~20mA load resistance <525 ohm
■ relay contact capacity: 1A / AC250V 3 group relay can be set
■ accuracy: ± 0.5% annual drift <± 0.2FS
■ power: 20W
