YB-150A/YB-150B Stainless Steel Precision Pressure Gauge
Brand: Hengyuan
Model number: YB-150
Type: Precision pressure gauge
Measuring range: 0-100 (MPa)
Accuracy level: IP65
Connection type: thread
Nominal diameter: 150 (mm)
Ambient temperature: 85 (℃)
○ precision pressure gauge use environmental conditions: 5~40℃, the relative humidity is not more than 80%,
and the environmental vibration and the fluctuation of the pressure source have no effect on the accurate reading of the instrument.
○ Precision pressure gauge temperature influence: If the ambient temperature deviates from 20 ± 3℃ (type A) or 20 ± 2℃,
consider the temperature additional error of 0.4% / 10℃ (type B)
○ Precision pressure gauge Weight: 1kg (Type A)?1.4kg (Type B)
